| Model NO. | MFA121-U35 | Focal Length(mm) | 35 | ||||
| Image Circle Diameter (Φmm) | 1.2" | Magnification(x) | Adjustable | ||||
| Working Distance(mm) | Min.200 | MTF30 (lp/mm) | 200 | ||||
| Type | Fixed Focal Length | Support Cameras | 24M | ||||
| Max Diameter(RATIO) | F=4.0~16 | Supported Camera Resolution | 25M | ||||
| Length (mm) | 48.85 | ||||||
| Angle | H | 1'' | 18.81° | 1.1" | 21.33° | 1.2" | 22° |
| V | 14.9° | 16.01° | 19.09° | ||||
| D | 23.83° | 26.37° | 28.81° | ||||
| Distortion(TV) | <0.1% | Focus Distance(min) | 0.2M | ||||
| Flange Back | 17.526mm in air | Back Focus | 19.6mm in air | ||||
| Filter Screw Size | M35.5x0.5 | Dimension | Φ38.6x48.85mm | ||||
| Mount | C-Mount | Temperature Range | -10~+50°C | ||||
| Flange Back | -20~+60°C | ||||||
